14 Tooth 20 DP 0.375 in. Hex Bore Steel Gear, 0.6 in. width
HomeStore

14 Tooth 20 DP 0.375 in. Hex Bore Steel Gear, 0.6 in. width

14 Tooth 20 DP 0.375 in. Hex Bore Steel Gear, 0.6 in. width

$6.40
14 Tooth 20 DP 0.375 in. Hex Bore Steel Gear, 0.6 in. width—
$6.40

The Story

  • Specifications
    • Bore: 0.375 in. [9.5 mm] (3/8) Hex
    • Diametral Pitch: 20
    • Face Width: 0.575 in.
    • Finish: Zinc Plated
    • Material: 4140 Steel
    • Overall Width: 0.6 in.
    • Pitch Diameter: 0.7 in.
    • Pressure Angle: 14.5°
    • Teeth: 14
    • Weight: 0.039 lbs.

Description

  • Specifications
    • Bore: 0.375 in. [9.5 mm] (3/8) Hex
    • Diametral Pitch: 20
    • Face Width: 0.575 in.
    • Finish: Zinc Plated
    • Material: 4140 Steel
    • Overall Width: 0.6 in.
    • Pitch Diameter: 0.7 in.
    • Pressure Angle: 14.5°
    • Teeth: 14
    • Weight: 0.039 lbs.
